The LM-11 Series of Slitter / Rewinders
(single + multi-ply
)





The Paper Roll Business is growing rapidly everywhere. Multi-ply NCR/THERMO Rolls continue to experience rates of growth in both,
industrialized and Third-World Countries.
CONVERTEX' answer:
The LM-11 Series of Slitter/Rewinders for single/twin/triple-ply rolls, combining versatility and flexibility.

Handles NCR / THERMO / CARBONLESS/CB/CF/CFB ... with ease and is ideally suited for the manufacture of Credit Card Payment Slip Rolls in multiparts (American Express, Diners, Euro Card, Masters, Visa, etc.). It can also make twin & triple-ply Add/Fax rolls as well as ATM, POS and PLOTTER. With and without flexo printing. Max. web speed = 320 mtrs./min.
Airshaft/s, edge trim, rewind shafts and roll endmarker are standard.

Also included:

  • Auto Rider Roller
  • Auto Stop by Roll Length
  • Auto Stop by Roll Diamenter
  • Auto Twister






  STANDARD FEATURES OF THE LM-11 SERIES
Backstand with 1 or 2 or 3 unwind/s.
Each unwind equipped with its own air shaft, air brake and banana roller.
Banana roller/s covered with "VITTON" rubber, resistant against aggressive chemicals.
Driven and pneumatically actuated rider roller.
Rider roller showing 10% advance speed.
Individual setting of air brake/s.
Air brake equipped with fine regulation.
One of the two carrier rollers with metallized cover.
Lower knife shaft of "TUNGSTEN CARBIDE" or "POLYURETHANE".
Quick and high return of investment.



Operating widths: 1100 mms. (1-ply)
800 mms. (2-ply)
650 mms. (3-ply)
Approx. output: 7-9000 add rolls per shift
2-2500 fax rolls per shift
Standards: CE-ISO-VDE-VDMA.



The LM-11 represents effecient and inexpensive paper converting machinery to give you the competitive edge!



Flexo printing attachments available for the LM-11 Series as option.
1 or 2 colour/s. Front or reverse. Simple rubber roller or sophisticated ceramic roller. 80 resp. 160 mtrs./min. 300/600 mms. print repeat.





Broad range of fine accessories, customized options and genuine spare parts available on request.

For instance inline flexo printing of one or two colour/s with precise registration, edge guide systems, auto web tension control, auto-roll wrapper and low-budget shrink wrappers.











All hand made, custom built and fully guaranteed machinery to dramatically increase your sales.



From CONVERTEX- Germany, your single source supplier.





If you wish to receive more Infos, send for Colour Brochure "Booster-99".
